8W Flexible Neon Strip Tunable White 2700K - 5700K LED Neon Strip
6.5mm X 12mm
Quick Detail:
· Size 6.5mm x 12mm / 0.26" x 0.47" (W x H)
· UV-resistance(no yellowish)
· Underwater application
· Lumileds LED
· Maximum run length 5M@8W/m
· IP68 rating
· Cable entry directions: Front cable entry
· CE, RoHS, Reach, UL compliant
· Life Span >54000H
· 5 Year Warranty
Specifications:
| Tech Date | |
| Model | LFSM-IQ |
Unit Cut | 50mm |
| LED PIN Temperature | Max.65℃ |
| Storage Temperature | -25℃ ～ +60℃ |
| Life span | >54000hrs |
| Certification | CE, RoHS, Reach, UL |
| IP Grade | IP67 |
| Warranty | 5 Years |
| Max. Run Length | 5M |
| CRI | Ra80 |
| LED Color | Tunable white |
| Voltage | DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature | 2700K+5700K |
| Power(W/M) | 8W/m |
| Lumen | 323lm/m@8W/m |
Download datasheet:
JRLite Linkedin: https://www.linkedin.com/company/jrlite (Neon Supplier from China)
Notices:
1. Please light it up for a quick check before installation.
2. Bending diameter of LEDLINE FLEX SINI is 60mm, do not bend to
side direction, or bend too sharp or twist. If bend it wrongly, PCB
inside will be damaged and the lighting fixture will not turn on.
3. During installation, please make sure there are at least two
workers to cooperate together and strictly follow the instruction
manuals.
Applications:
Designed to create an appropriate atmosphere by the color and light
adjustment from 2700K to 5700K.
Activate harmonious dynamic lighting scenes.
Living room, coherence room, banquet hall.
Functional combined solution.
FAQ:
Commercial CE RoHS Reach UL Certificate Indoor IP20
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. What about the lead time?
A: 2-4 weeks after payment.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive.
Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the samples and places deposit for formal
order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production.
